Iron Fist

Marine specific, truly customisable cranes

IRON FIST cranes are designed and built specifically for the marine environment making them unique in the market. Italian design and manufacturing combine to create high quality cranes with reliability and durability at the forefront of design. IRON FIST cranes are built with marine specific materials and paint application and are designed to comply with all the necessary certification requirements.

We recognise every work environment is unique, which is why all IRON FIST cranes are fully customisable with numerous optional features to meet your requirements and maximise efficiency.

If there is a crane or product not shown here that you’re interested in then please get in touch and we will be able to offer a solution.

Fully Foldable Knuckle Boom Crane

Fully foldable telescopic boom cranes are an excellent solution where installation space is very limited or for a smaller vessel. The design of these cranes, as the name suggests, allows them to be folded into a compact triangular shape when stowed significantly reducing the overall dimensions.

With a wide range of sizes of fully foldable knuckle boom cranes to choose from there is a crane to suit all applications in the marine industry, from a small mussel farming vessel lifting one tonne to SOV’s with a compact stow point.

Sophisticated crane geometry, compact design ideal where space is limited

APPLICATIONS

Fish farming vessels
Wind farms
Crew transfer vessels
Marine civils
Offshore supply vessels
Workboats and multicats

FEATURES

Compact stow position
Fully customisable design
Versatile application
Highest marine grade specification for surface preparation and paint application
Model options with lifting capability of over 30 tonnes.
Outreach over 20 meters
Rack & pinion single and double slewing cylinders as well as continuous slewing system

OPTIONS

Hydraulic Power Unit
Control position to suit application
Radio remote control
Multiple hydraulic attachments
Wire rope winch
Arctic environment specification
Explosion proof

Stiff Boom Crane

Stiff boom cranes are typically ideal for material handling and unloading. With its predictable movements and simple control making it a safe and fast solution for a range of applications.

Fitted with a winch rated to match the cranes structure as standard the simplicity of their design offers a cost-effective alternative to those with an articulated arm. The fixed arm, without hydraulic extension and secondary hinges also makes it a lower maintenance option.

A stiff boom crane can be a simple and cost effective solution for a range of applications

APPLICATIONS

Dockside
Service cranes
Hose handling cranes
Provision and cargo handling cranes

FEATURES

Model options with lifting capability of 100 tonnes.
Jib radius up to 50 meters
Highest marine grade specification for surface preparation and paint application
Operation of crane by remote of control platform on crane
Capability for integrated electro hydraulic drive / HPU
Continuous slewing
Low / high temperature operations
Anti-collision system

OPTIONS

Hydraulic Power Unit
Control position to suit application
Radio remote control
Multiple hydraulic attachments
Wire rope winch
Personnel Lifting
CT (Constant Tension)
AHC (Active Heave Compensation)
AOPS (Automatic Overload Protection System)
MOPS (Manual Overload Protection System)
Arctic environment specification
Explosion proof

Telescopic Boom Crane

A flexible yet compact crane, the telescopic boom crane has a wide operational radius whilst allowing you to store the crane in a compact position. The simplicity of the design means that is a lower weight crane and is straightforward to maintain.

IRON FIST telescopic cranes can be customised to your requirements for reach and lift. Built to comply with all certification requirements and to a high marine specification.

A wide radius crane whilst maintaining a compact size when stored.

APPLICATIONS

Fishing and fish farming vessels
Service cranes
Provision and cargo handling

FEATURES

Model options with lifting capability of 50 tonnes.
Jib radius up to 40 meters
Highest marine grade specification for surface preparation and paint application
Operation of crane by remote of control platform on crane
Capability for integrated electro hydraulic drive / HPU
Continuous slewing
Low / high temperature operations
Anti-collision system

OPTIONS

Hydraulic Power Unit
Control position to suit application
Radio remote control
Multiple hydraulic attachments
Wire rope winch
Personnel Lifting
CT (Constant Tension)
AHC (Active Heave Compensation)
AOPS (Automatic Overload Protection System)
MOPS (Manual Overload Protection System)
Arctic environment specification
Explosion proof

Knuckle Boom Crane

The knuckle boom cranes offer a superior operating speed and lifting capacity when stowing position and space are not limited compared to a fully folding version.

IRON FIST knuckle boom crane are available with both a folding and telescopic option with large lifting capabilities of up to 600tm making them ideal for offshore installation where lifting a high load is required with complete control.

IRON FIST knuckle boom cranes can be customised to your requirements for reach and lift. Built to comply with all certification requirements and to a high marine specification.

IRON FIST knuckle boom cranes are also available in Telescopic and Fully Foldable configurations.

APPLICATIONS

Service cranes
Provision and cargo handling cranes
Piping & boat handling
Fishing and fish farming cranes
Container and cargo handling cranes

FEATURES

Model options with lifting capability of up to 600tm.
Jib radius up to 50 meters
Highest marine grade specification for surface preparation and paint application
Operation of crane by remote of control platform on crane
Capability for integrated electro hydraulic drive / HPU
Continuous slewing
Low / high temperature operations
Anti-collision system

OPTIONS

Hydraulic Power Unit
Control position to suit application
Radio remote control
Multiple hydraulic attachments
Wire rope winch
Arctic environment specification
Explosion proof
